    FLYLINE SINE WAVE UPS CUM INVERTER (Two-in-One System)

    We are manufacturing Duel Inverter which works as an Inverter cum UPS and is an unavoidable electronic equipment in home as well office or at any business centers. The main advantage of Dual Inverter or Two-in-one UPS is to save money by purchasing the same instead of Inverter and UPS separately. An uninterrupted power supply system can be considered a life saving device as it helps to avoid serious situations such as fatalities that could occur in a hospital due to a lapse in power supply or a loss of important data and many other serious power disruptions.

    FLYLINE SINE WAVE UPS CUM INVERTER FEATURES- ( Two-in-One System ):

    ►Pure sine wave system can use as UPS for computer as well as inverter for lighting a house.► UPS and Inverter mode selection switch. ► Maintenance Free. ► Attractive Designs. ► Low Power Consumption. ► No load charging system. ► It provides low power consumption (bypass circuit). ► Single Switch Operation. ► Fully automatic. ►DSP based very low component cost design. ► Single sided PCB, easy to assemble without any SMD components. ► Auto resetting. ► Protection from lightening, High/Low Voltage Trip. ► Over Load Protection. ► Over Charge and Deep Discharge cut off. ► Independent Digital display for charging voltage, main voltage, inverter voltage, load etc. ► Audio and Visual Indicators.► Can connect to the existing wiring. ► Bridge type center aligned switching MOSFET based topology. ► Settable SMPS intelligent charging system. ► No husking sound.


    SL.No.    		 Parameter Single Phase Unit
    1 Rating 650 VA to 6000 V A
    2 Input Voltage Range 180V-270 AC or Solar power 12,24,36 or 48V
    3 Normal Output Voltage 230V AC
    4 Output Frequency 50 Hz ± 1 %
    5 Input Frequency 45 - 55
    6 Power Factor -0.8 Lagging to unit
    7 Efficiency 95%
    8 Control Digital/Analogue
    9 Winding Copper Wires
    10 Wave Form Pure Sine Wave
    11 Mounting Free Free
    12 Compact in size, Can work on Generators
    13 Charging - AC or Solar Power Floating type & Trickle charging.
    14 Noise Low Noise <50db
    15 Battery 12, 24 or 48 V
    16 Heat < 40° C
